Product description
With the Pressure sensor A-10 12852822 from Wika you measure gauge pressure in general industrial applications.
- Measuring range: 0 ... 1 bar gauge
- Process connection: G 1/4 A DIN EN ISO 1179-2
- Output signal: 0 ... 10 V, 3-wire
- Power supply: 14...30 V DC
- Electrical connection: valve connector, size A
- Sealing: NBR
- Permissible medium temperature: 0...+80°C
- Non-linearity: 0.5% BFSL
- Wetted parts / case: 316L
- Approvals: cULus
- Data sheet: PE 81.60
Not sure about the right version? Ask for advice or order the A-10 directly from Ebora.
