318-14571/14541C4400BORODN50 Rond inlas/oplas RVS kijkglas 14571/14541 C4400 BORO DN50

Welke lengte heeft u nodig?
/
U heeft 0 stuks nodig voor 0 euro incl. BTW
Size connection
Sealing
Version sight glass
Optie: reserve glas
Gehard borosilicaatglas Drukklasse: PN7
Ask for quotationAdd to wish list

The specified delivery times are the working days or working weeks specified by the manufacturer.

If the delivery time is critical for you, please contact us so that we can check the delivery time for you.

Price and delivery time on request
Add to favorites

Why Ebora :

  • We think with you
  • Clear offers
  • Flexible and proactive
  • knowledgeable
  • knowledgeable
  • Product description and specifications
  • Documents
  • Ask a Question

Product description

Round Sight Glass
PN 2.5, Light construction
For welding, similar to DIN 28120

Application:
Observation and illumination of the interior of enclosed vessels (boilers, tanks, silos etc.).
Sight glasses consist of round flange mountings to be welded into or onto a vessel, completed by a sight glass plate with appropriate seals.


Materials:
Flange: 1.4571 (Base Flange), 1.4541 (Cover Flange)
Glass: Borosilicate glass DIN 7081, Soda Lime Glass DIN 8903
Seal: C4400, PTFE, Silicone
Bolts: A4-70

Other materials on request

Installation guideline:
After welding the base flange onto/into the pressure vessel, the sealing surface must be checked for deformations! Reworking may be required!

The pressure rating does not consider the base flange. This will have to be audited together with the pressure vessel according to AD 2000 instructions B9 or equivalent standard!

Special constructions/Options
a) Wiper
b) Double layered glass
c) LED Lights
d) O Ring Seal (vacuum capable)
e) Additional special constructions on request

Example:
ACI Type 318
DN100
Flange 1.4571 / 1.4541          11-318-100-1-1-1-000
Borosilicate glass
Seal PTFE
Standard Contruction

Recommendation:
For corrosive media or steam, we recommend adding a mica disk to protect the glass!

Old type:
EB118


Documents

Specifications

Type of articleSightglasses
Pressure rating PN2,5
Shape Round
BrandEbora
CategorySightglasses
Tags Ebora Appendages Kijk en Peilglazen 318-14571/14541C4400BORODN50
Product code10113670
UnitPiece (s)
